Rugged Ridge LED Interior Courtesy Light, 07-14 Jeep Wrangler (JK) User Manual
Universal led light
12430.01
Rev. 5/11
Page 1 of 1
SB
JK Header installation:
Step 1. Remove the mounting plate from the LED light by sliding to the side.
Step 2. Place the mounting plate on the soft top header centering it
between the visors and marking the mounting holes.
Step 3. Use the supplied screws to make the mounting holes for the light.
Use moderate pressure to get the screws started. Once both holes
have been made remove the screws and attach the mounting plate.
Step 4. Attach the light to the mounting plate by lining up the tabs and
sliding to the side to lock in place.
Note: The light will clip in and line up with the mounting plate in
only one direction.
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE YOU BEGIN.
For Technical Assistance Contact:
OMIX-ADA Tech Support
Phone: 1-800-449-6649
Email: [email protected]
Web: www.Omix-Ada.com
The universal LED light can be mounted to any hard flat surface. Below is a
suggestion for use as a dome light in a JK.
UNIVERSAL LED LIGHT
LED light uses 3 AAA batteries.
(Not Included)
