Rugged Ridge Automatic Transmission Shift Knob, Billet, 07-10 Jeep Wrangler (JK) User Manual
Auto trans shift knob billet aluminum jk 07-10

Rev. 10/11
Page 1 of 1
SB
11421.01 Brushed
11422.01 Black
Auto Trans Shift Knob Billet Aluminum JK 07-10
Step 1. Remove the factory shift handle. Using a flat blade screwdriver
pry the lower shift handle cover down.
Step 2. Using a T15 torx bit remove the handle lock screw. Do not
discard the screw it will be used to hold the new handle on.
Once the screw has been removed slide the handle up and
remove.
Step 3. Slide the new handle onto the shifter shaft. Align the set screw
hole. Insert the set screw previously removed and tighten. Test
shifter for proper function before operating vehicle.
Contents: Shifter Handle (1)
For Technical Assistance Contact:
Omix-Ada Tech Support
Phone: 1-800-449-6649
Email: [email protected]
Web: www.Omix-Ada.com
Copyright Omix-Ada 2011
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE YOU BEGIN.
