13. Secure using (1) 14 X 1 ¾” Sheet Metal Screw provided.
NOTE: For more support you opt to install (2) Sheet Metal Screws in the front
of the console.
13101.xx console used in image. For 13103.XX open the front locking
Compartment to gain access to front of console.
Figure 9
Ensure that all Screws are securely fastened to the vehicle
prior to traveling.
Section Two- Installation Instructions
1. Position the Console in the desired position between the Driver and
Passenger seats as shown in Figure 1.
2. Adjust the position of the Console front to back and ensure that the shifter
clearance for all gears is not obstructed by the Console position (Figure 2)
NOTE: Position the Console as far forward as possible without interfering
with the shifter.
3. Remove the rear cup holder to gain access to the rear most section of the
console. Drill (2) holes through the rear of the Console and floor of the
vehicle using 3/16” drill bit.
4.
Figure 1 Figure2
