Rugged Ridge All Terrain Fender Flares, 99-07 Ford F-250, F-350, F-450 Trucks User Manual
Rugged Ridge For the car

Page 1 of 2
81630.01
2. Clean inside mounting lip edge with rubbing alcohol. Install edge trim as
shown by removing red vinyl tape covering only a few inches at a time. Do not
stretch the trim while being applied, this may cause shrinkage after installation.
Trim excess off.
CONTENTS:
1. Fender Flares (4)
2. M8 Socket Head Cap Crews (36)
3. M8 Flat Washers (36)
4. M8 Locking Hex Nuts (36)
5. U - Clamps (8)
6. Plastic Square Tabs (8)
7. Phillips Head Screws (8)
Ford Super Duty All Terrain Flare Kit
1. Install the supplied trim hardware onto the flares. Place a washer on the bolt
and insert the bolt through the hole in the flare. Place a lock nut on the back
side of the flare to secure the bolt.
3. Remove factory screws located in wheel well housing as indicated in the
image. Install the flare using the factory screws removed. When installing the
flare moderate pressure against the outside of the flare pushing towards the
vehicle will be needed for installation. Repeat this procedure for the other front
flare.
4. Remove the 10 MM bolt in the bottom front area of the rear fender wells.
Place the fender flare in place using the 10 MM bolt to position the flare. With a
marking pen, mark the mounting holes in the fender well area using the mounting
holes in the flare as a guide.
Rev 4/22/10
