Rugged Ridge Radiator Bug Shield, Black, 55-86 Jeep CJ Models - Manual

Bug Shields 11106.01 – 11213.02 (7619) (7410) 1955 – 1986 CJ
11106.02 - 11213.01 (7615) (7440) 1987-1995 YJ Wrangler
11106.03 - 11213.03 (7639) (7439) 1997-2006 TJ Wrangler
Installation Instructions
Note: The supplied bug screen has been design to be mounted on the outside
of the vehicles grille. Drilling will be required for proper mounting.
Step(1)
Position the bug shield over the vehicles grille and mark the location of the
mounting holes. An additional person may be required for proper alignment.
Mark the hole locations as seen in (Fig.1). Remove the bug shield and drill
holes where marked. It is recommended that a matching paint color or a
silicon sealant be applied to the holes after drilling. This will protect the
exposed metal finish from the elements. Repeat for other three mounting
points
Step(2)
Install bug shield with supplied screws from the outside of the grille (Fig.2).
Repeat for other three screws.
Note: For proper installation drilling and installation of the supplied screws
is recommended, but plastic lock straps (not supplied) can be used (Fig.3)
Fig. 1 Fig.2 Fig.3
