Rugged Ridge Mirror Relocation Brackets, Black, 03-06 Jeep Wrangler User Manual
Rugged Ridge For the car
1997-06 TJ
Mirror Relocation Brackets
11025.03 - Black
11026.03 - Stainless Steel
Page 1
Step 1.
Remore the three bolts that
retain the factory door mirror. Remove the
factory mirror.
Step 2.
Remove the two side door
hinge bolts. The factory uses threadlock to
retain these bolts, so some effort may be
required.
Step 3.
Using the included hardare,
install the relocation bracket using the
existing factory door hinge bolt holes.
Install both bolts loosely. Note that the
relocation bracket points forward.
Step 4.
Tighten both bolts snugly.
Step 5.
The relocation bracket is now
installed.
Step 6.
Place the factory mirror onto
the relocation bracket, taking care to
align the mounting bolt holes. Using the
included hardware, insert the bolts through
the mirror and bracket mounting holes.
Step 7.
Place one washer on each bolt,
followed by one nut (included). Tighten the
nuts snugly, taking care not to over tighten.
Step 8.
Installation is now complete.
Repeat procedures for other side.
