Rugged Ridge Tube Doors, Locking, 97-06 Jeep Wrangler (TJ) - Manual

Page 1 of 3
Contents:
Tube Door (latches installed) (2)
Mirror Mounting Bolt (6)
Adjustable Nylon Strap (2)
Anti-Rattle Bumper (2)
Self Tapping Screw (2)
TJ TUBE DOORS
11509.20 Tube Doors
This product is intended to provide added “off-road” convenience and utility to your vehicle.
This product is not intended to provide occupant containment or protection in the event of an accident or roll-
over. Further, “on road” use may involve increased risk of serious injury in the event of side-impact accidents. To
reduce risk from these types of injuries: Always wear seat belt and shoulder harness for all vehicle occupants.
Keep arms and body inside vehicle. Drive safely, read and understand all manufacturers warnings and product
instructions before installation.
3. Remove the nuts from the bottom of each factory hinge pin.
Set these nuts aside to be re-installed on the Tube Doors. To remove the
factory doors, carefully lift the door upward until the hinge pins completely
clear the hinges. Store OE doors in a safe place.
2. Locate the driver side door strap that limits the door opening. Remove
the strap from the hook located inside the vehicle. NOTICE ! The door can
swing open into the vehicle once the strap is released potentially causing
damage to your vehicle.
1. Remove the (3) torx head bolts that secure the side mirror to the
vehicle. Be sure not to let the mirror drop after removing these bolts. Set
mirrors aside to be re-installed on the Tube Doors.
