Rugged Ridge Oil Dipstick Handle, Billet, 97-11 Jeep Wrangler User Manual
Jk billet aluminum oil dipstick handle 97-11

Rev. 10/11
Page 1 of 1
SB
11430.07 Brushed
11431.07 Black
Contents: Oil Dipstick Handle (1)
PLEASE READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE YOU BEGIN.
Step 1. Using a small punch press the pin out that holds the
dipstick in the factory handle. Do not discard the
pin it will be reused. Carefully remove the O-ring
from the factory handle and install in onto the new
handle .
For Technical Assistance Contact:
OMIX-ADA Tech Support
Phone: 1-800-449-6649
Email: [email protected]
Web: www.Omix-Ada.com
Copyright Omix-Ada 2011
Care and Maintenance:
Use soap and water to clean the aluminum
surface. Regular cleaning with help maintain
the appearance. Do not use harsh chemicals.
JK Billet Aluminum Oil Dipstick Handle 97-11
Step 2. Install the small sleeve over the end of the dipstick.
Insert the dipstick and sleeve into the handle. Align
the hole in the dipstick, sleeve and handle.
Step 3. Align the hole in the dipstick, sleeve and handle.
Insert the pin removed from the factory handle
using a small punch to set the pin.
