Rugged Ridge Cold Air Intake Kit, 2.5L, 91-95 Jeep Wrangler (YJ) - Manual

17750.05
YJ 91-95 Air Intake Kit - 2.5L
Contents:
1. Intake Tube Front (1)
2. Intake Tube Rear (1)
3. Heat Shield (1)
4. Air Filter (1)
5. Rubber Hose Elbow (1)
6. Rubber Tube Coupler (1)
7. Breather Hose (1)
8. Power Steering Hose (1)
9. Rubber Isolator Mount (1)
10. M8 Washer (2)
11. M8 Nut (2)
12. M6 Bolt (2)
13. M6 Nut (2)
14. M6 Flat Washer (2)
15. Edge Trim (1)
16. #56 Hose Clamp (2)
17. #48 Hose Clamps (2)
18. #40 Hose Clamp (1)
1. Remove original air intake system including air filter housing, air filter, breather hoses, and inlet duct.
2. Remove rubber grommets from the air filter housing bracket. Remove (2) Phillips head screws from radiator
fan shroud. If vehicle has power steering remove the flat head screw securing power steering fluid reservoir in
place. For easier installation, unbolt front end of radiator support rod and rotate out of engine compartment.
Page 1 of 3
19. Spacer (2)
20. 1-1/16” Hose Clamp (4)
21. 1/4-20x3/4” Bolt
22. 1/4-20 Nut
23. 1/4” Flat Washer
24. Zip Tie (2)
