Rugged Ridge 3-Inch Double Tube Rear Bumper, 55-86 Jeep CJ Models User Manual
Rugged Ridge For the car
Installation Instructions
Rear Tubular Bumper
1955 - 1986 CJ5 - CJ7
Parts List: (1) Rear Tube Bumper
(8) 10mm Nuts
(4) 12mm Bolts
(4) 12 mm Lock Washers
(2) Rear mounting Brackets ( L & R )
(16) 10mm Flat Washers
(8) 12mm Flat Washers
(8) 10mm Bolts
(8) 10mm Lock Washers
Step (1)
Remove the factory rear bumperett brackets.
For some aplications the rear body mount and bolt may need to be removed to allow
the top bolt to be removed and installed.
Step (2)
Locate the left and right bumper mounting brackets. Place left bracket with large vertical
tab facing outwards, towards the inside of the vehicle. For 1955 -86 CJ's the holes in
the frame crossmember will line up (Use the inner mounting holes on the supplied brackets).
temporarily mount the brackets into place.
