Rugged Ridge 3-Inch Double Tube Front Bumper, 84-96 Jeep Cherokee (XJ) User Manual
Rugged Ridge For the car
Front Tube bumper
84-95 Cherokee XJ - MJ
P/N: 11560.80
NOTE:
To obtain the correct
installation, we recommend
that you follow these
instructions carefully. Please
take care when installing
this product to protect the
finish and your investment.
The help of a second person
is recommended.
Parts List: (1) Front Tube Bumper
( You Will Be Reusing OE)
(Original Mounting Hardware)
Installation Instructions:
(Step 1)
Remove the front bumper. Front bumper is held in place by two side brackets and (6) 15mm bolts
located on each side of the sub-frame.
(DO NOT DISCARD 15mm BOLTS THEY ARE TO BE REUSED).
Disconnect the vapor bottle on the passenger side and allow to hang to the side for now.
