Rugged Ridge Heavy Duty Tire Carrier Mount, 87-06 Jeep Wrangler User Manual
Yj / tj heavy duty tire carrier
11585.01
YJ / TJ Heavy Duty Tire Carrier
Contents:
1. Tire Carrier (1)
2. Angle Bracket (1)
3. M12 x 1.25 x 35 Bolts (3)
4. M12 Lock Washers (3)
5. M12 x 1.25 Lug Nuts (3)
6. M8 x 25 Bolts (6)
7. M8 Lock Washers (6)
8. M8 Nuts (6)
9. M8 Flat Washers (12)
1. Remove spare tire. On vehicles equipped with a third brake light, remove wiring cover inside the tailgate.
Note where each wire is attached, then disconnect and route wires out of the cover bracket.
Page 1 of 3
2. Pass Third Brake Light wiring through tail gate. Remove Third Brake Light assembly.
