Rugged Ridge Steering Box Skid Plate, 87-95 Jeep Wrangler (YJ) - Manual

87-95 YJ STEERING SKID PLATE
Page 1 of 2
2. Remove top rear steering box bolt as shown.
This step is necessary to gain access to the side steering
box bolts with a socket in step 2.
3. Remove two side steering box bolts as shown.
These holes will be used to mount the steering box
skid plate.
4. Place skid plate in location to line up with the two side steering box holes. Use the supplied 12mm hardware
to mount skid plate. Do not use lock washers at this time. Hand tighten only as the skid plate will have to be removed.
Mark the two front mounting holes on the bottom of the bumper. Remove skid plate and drill holes to 3/8” diameter.
18003.11
Contents:
1. YJ Steering Skid Plate (1)
2. 12mm Hex Bolt (2)
3. 12mm Flat Washer (2)
4. 12mm Lock Washer (2)
5. 8mm Hex Bolt (2)
6. 8mm Flat washer (small) (4)
7. 8mm Lock Washer (small) (2)
8. 8mm Standard Nut (small) (2)
