PeCifiCations
Dimensions
• Height - 22.25” (56.5 cm)
• Width - 26.75” (67.9 cm)
• Depth - 16.50” (41.9 cm)
Circuits
• Six (6) syrup, plus soda and water
Electrical
• 115V/60 Hz/16.0 Amps
•
230V/50 Hz/8.0 Amps
• 20 amp circuit required
• Includes a 6-foot grounded cord
Refrigeration
• 1/3 HP, R134a refrigerant
Water Bath
• Roto-molded polyethylene
Insulation
• Polyurethane foamed-in-place
Ice Bank
• 35 lbs (15.9 kg)
Maximum Draw Rate
• 6 oz drinks - 460 at 4 per min
• 12 oz drinks - 253 at 2 per minute
• Based on a 40ºF (4.4ºC) or below
dispensed drink, ambient and
incoming syrup and water at a tem-
perature of 75ºF (23ºC)
Recovery
• 3 six ounce drinks per minute
Pull Down
• 6.9 hours operational
Maximum Distance to Dispensers
• 150 ft (46 m)
Carbonator
• Integral cold carbonator
Carbonator Pump
• 100 gph (378 lph)
Carbonator Motor
• 1/3 HP (.25 kW)
Circulating Pump
• 70 gph (265 lph)
Circulating Motor
• 1/3 HP (.25 kW)
Shipping Weight
• 143 lbs (65 kg)
Operating Weight
• 261 lbs (119 kg)
Shipping Cube
• 9.8 cu ft (.278 cu m)
Options
• 4” Adjustable legs (up to 5-1/2”)
S
PeCifiCations
S
tandaRd
F
eatuRes
• Modular lift-out refrigeration system for
easy in-field service
• High capacity refrigeration and recirculation
for high volume and remote long distance
installations
• CFC-free R134a refrigerant
• Light-weight, roto-molded water bath with
drain
• Up to six (6) syrup circuits with recirculating
soda and water
• Polyurethane foamed-in-place insulation
• Self-contained carbonation system
LC84 CONQUEST
1/3 HP Post-Mix Remote
LC84 CONQUEST
16.5
0”
26.7
5”
NOTE: Clearance of 12”
required around unit for
maintenance and air flow.
22.25”
