5.2 Product Configurator
Figure 1. Product Configurator for Regulator 20313
EXAMPLE: 20313S6WQ2
Option
Blank NPT porting
Adjustment Method ‐ MS SAE porting
‐ SS Stainless steel Flanges & trim
Blank Manual
F Pneumatic failsafe motor
G Hydraulic failsafe motor Regulated Pressure Range
Blank High sensitivity 300 ‐ 1600 psi (21 ‐ 110 bar)
‐1 Full range 300 ‐ 3000 psi (21 ‐ 207 bar)
Series
1/2” Shear‐Seal Regulator 20313S6WQ2
