P

D

With seat cushion lying plastic side

up, line up [4] holes in seat plate (A)

with [4] holes in seat cushion (H).

Attach with [4] 3/4” black screws

(N). Tighten securely. Please Note:

Foot bar should face front of seat

cushion (Front of cushion has label

attached.)

A

1.

Place base (E) face down and push

castors (F) in firmly. Insert cylinder

(B) through base cap into chair

base. Twist and press firmly.

Slide Bellows (C) down over

cylinder.

C

B

E

F

4.

Take the complete seat assembly

and insert the seat plate over the

cylinder (B) by inserting the cylinder

into the hole on the bottom of the

seat plate (A).

5.

Attach backrest plate (P) to backrest

support bar (D) by inserting back-

rest support bar “T” into longated

slot in backrest plate (P). Continue

with Step 7.

6.

B

THIS STEP IS ONLY FOR

MODEL 91-6008

Attach foot bar (J) to base plate (A)

using [4] Silver Bolts (M) and [4]

nuts (L). Line up holes in footbar to

holes in seat plate. Tighten securely.

2.

J

L

A

K

A

D

Attach support bar with bellows (D)

to seat plate (A) by sliding the bar

into the raised area of the seat plate

(see arrow for location).

Thread Knob (K) into hole in seat

plate, making sure knob threads

through seat plate.

3.

NOTE:

FIG. Shown with

Footbar. Model

91-6009 not equipped

with Footbar.

NOTE:

FIG. Shown

with Footbar.

Model

91-6009 not

equipped

with Footbar.

NOTE:

FIG. 5.

Shown with

Footbar.

Model

91-6009 is

not equipped

with

Footbar.

M

H

MUD0107

PAGE 2

N
