8. B
LADE
I
NSTALLATION
THE FOLLOWING OPERATION MUST BE ACCOMPLISHED BEFORE
INSTALLING THE LIGHT KIT.
Large blades (Lower section):
1. Insert the blade into the blade holder, align holes from blade to blade holder
and secure with two screws provided (Fig. 17).
2. Repeat process with the other blades.
Small blades (Upper section):
1. Insert the blade into the blade holder, align holes from blade to blade holder
and secure with two screws provided (Fig. 17).
2. Repeat process with the other blades.
Fig. 17
Screws
Screws
Large blades
Blade holder
Blade holder
Small blades
