Attaching the fan blades – Minka Group F571-DRF User Manual
Page 16
Step 1. Attach the fan blade to the blade
bracket using rubber washer and screws provided.
Tighten screws securely. Repeat for remaining
blades. (Fig. 14)
Step 2. Remove and discard the rubber stops from
the motor.Align holes in blade bracket and motor
and secure with proper screws. Repeat process
with the other blade brackets.(Fig. 15)
ATTACHING THE FAN BLADES
7
Fig.14
RUBBER WASHERS
FAN BLADE
BLADE BRACKET
Fig.15
FAN MOTOR
FAN BLADE
BLADE BRACKET
