HANGING THE FAN
4
REMEMBER to shut the power off at the circuit breaker or fuse box.
Step 1. Secure the hanger bracket to the ceiling outlet box using screws
provided with the outlet box and flat washers included with the fan.
(Fig. 5) Note: Optional wood screws are provided for mounting of
hanger bracket directly to buliding structure.
Step 2. Loosen the two set screws in the top coupling of the top
housing assembly. (Fig. 6)
Step 3. Remove downrod hanger ball by loosening set screw, removing
the cross pin, and sliding ball off rod. Remove the hitch pin and lock
pin.(Fig. 7)
Step 4. Carefully feed fan wires up through the downrod and then
through the holes in the rubber cap on the top of the downrod. Insert
the rod into the coupling and tighten onto fan until the holes are
aligned. Next, replace lock pin and hitch pin. Tighten the set screws.(Fig.
8)
Step 5. Slip coupling cover, and canopy onto downrod. Let canopy rest
on top of the coupling cover.Carefully reinstall hanger ball onto rod
being sure that cross pin is in correct postition, set screw on hanger ball
is tight and wires are not twisted.(Fig.8)
Step 6. Now lift motor assembly into position and place downrod ball
into hanger bracket. Rotate until the check groove has dropped into the
registration slot and seats firmly. Rod should not rotate if this is done
correctly.(Fig.9)
WARNING: All of the parts, hardware and components such as the
hanger bracket and hanger ball have been provided for your safety
and the proper installation of your new ceiling fan. The use of other parts,
hardware or components not supplied by Minka Aire with the fan will
void the Minka Aire Warranty.
