2
1. Fan Blades (3)
2. Mounting bracket
3. Fan motor/housing ass'y
4. Blade support plates (3)
5. Light kit mounting plate
6. Light plate
7. Glass shade
8. Metal light cover (for optional use)
9a. Wall transmitter Incl. 2 mounting
screws and 3 wire nuts
9b. Wall plate w/2 mounting screws
10. Extra Wall Plate w/2 Mounting
screws
11. 100W Mini-Can halogen bulb
12. Balancing kit
A. Mounting hardware:
#10 x 1.5" Wood screws (2)
#8 x 3/4" Machine screws (2)
Lock washers (2)
4mm star washers (2)
Wire nuts (3)
Washers (2)
B. Blade attachment hardware:
3/16" x 12.3 mm Screws (10)
Rubber washers (10)
PACKAGE CONTENTS
1
2
4
3
8
9a
9b
7
5
6
Unpack your fan and check the contents. You should have the following items:
A
B
11
10
12
