F594-e-p7, Blade installation – Minka Group F594-ORB User Manual
Page 14
7
Fig. 7
BLADE INSTALLATION
THE FOLLOWING OPERATIONS MUST BE ACCOMPLISHED BEFORE INSTALLING THE LIGHT KIT.
THE FOLLOWING OPERATIONS MUST BE ACCOMPLISHED BEFORE INSTALLING THE LIGHT KIT.
Insert one fan blade into the blade slot on the motor housing and secure with the screws, rubber
washers and blade support plate. Securely tighten screws. Repeat process with other blades. (Fig. 7)
Screws with rubber washers
Blade support plates
Blades
Slots
