Attaching the fan blades – Minka Group F889-BNW User Manual
Page 15
7
ATTACHING THE FAN BLADES
Insert one fan blade into the blade slot on the motor
housing and secure with the blade support plate, lock
washers, and screws. Securely tighten screws. Repeat
process with other blades. (Fig 14) Secure the last screw
through the blade hole. (Fig 15)
Fig. 15
FAN BLADE
SLOT
BLADE SUPPORT
PLATES
SCREWS WITH
LOCK WASHERS
Fig. 14
