Minka Group F889-BNW - Manual (Page 13)

Step 1. Motor to House Supply Wires Electrical Connections: Connect the WHITE wire (Neutral) from
the outlet box to the WHITE wire marked "AC in N" from the motor. Connect the BLACK wire (Hot)
from the outlet box to the BLACK wire marked "AC in L" from the motor. Secure all wire connections
with the plastic wire nuts provided. (Fig. 12)
Step 2. If your outlet box has a GROUND wire (Green or Bare Copper) connect this wire to the
Hanger Ball and Hanger Bracket Ground wires. If your outlet box does not have a Ground Wire, then
connect the Hanger Ball and Hanger Bracket Ground Wires together. Secure wire connection with
the plastic wire nut provided. (Fig. 12)
After all splices are made, check to make sure there are no loose strands. As an additional precaution
we suggest to secure the plastic wire connectors to the wires with electrical tape.
WHITE (NEUTRAL)
WHITE ("AC IN N")
GREEN OR BARE
COPPER (GROUND)
GROUND
(GREEN)
(CONNECT TO
GROUND WIRE
ON HANGER
BRACKE IF NO
HOUSE GROUND
WIRE EXISTS.)
BLACK (HOT)
BLACK ("AC IN L")
Fig. 12
