9. TYPICAL FOCUS SERIES ILLUSTRATION
NOTE: Your unit may vary from this typical diagram.
1
Top Grid, Standard
2
Radiant
6
Grease Box
7
Water Tub, Large
8
Water Tub, Medium
10
Knob, Main Burner
11
Knob, Runner Tube
15
Utility Bar
16
Service Shelf
20
Front Panel
21
Gas Valve,
Main Burner
29
Grate Support
31
Lower Back
30
Rear Burner
Support
26
Front Weldment
3
Burner
33
Reflector LH/RH
34
Reflector Middle
