Team Associated SC10.2 - Manual (Page 11)

11
:: Rear End Build - Bag E-EE - Step 2
:: Rear End Build - Bag E-EE - Step 3
:: Rear End Build - Bag E-EE - Step 4
6277
Ballstud .30
silver, long
9564
Rear chassis
brace
31286
FT ballstud
washer,
aluminum
(1mm)
x2
x2
6272
Dust cover
foam
x2
Use inside hole in
chassis brace!
!
9643
5-40x7/16
shcs
7488
Rear ballast
weight
x2
9644
5-40x9/16
shcs
7413
4-40x3/4
bhcs
9643
5-40x7/16
shcs
x2
x2
x2
1781
FT aluminum
shock bushing,
short
9824
SC10/T4 rear
shock tower
x2
#1596
thread lock
9269
5-40x1/2
fhcs
9269
5-40x1/2
fhcs
x2
x4
