j5 create JUD200 USB 2.0 Newport Station - Manual (Page 6)

NEWPORT STATION
USER MANUAL
5
Physical Specifications
Power
Power Button
Blue Light when power is supplied to the docking station.
Power Mode Self-powered
Power Adapter Input: AC 100-240V, 50~60 Hz
Output: DC 5V/3A
Host (2)
Upstream Port
USB 2.0 port( Mini-B Female Connector)
Hub (3.5.6)
Downstream Port
USB 2.0 Type-A Female Connector
Video(4)
VGA Port
DB 15pin Female Connector
Support Modes Extended, Mirror, Primary Display
Display Rotation: 0°, 90°, 180°, 270°
Resolutions and Color
Depth
Aspect Ratio Resolution Color Depth
Wide Screen Display
16:10 1920 x 1200 16,32 bits
16:9 1920 x 1080 16,32 bits
16:10 1680 x 1050 16,32 bits
16:9 1600 x 900 16,32 bits
16:10 1440 x 900 16,32 bits
16:9 1360 x 768 16,32 bits
16:10 1280 x 800 16,32 bits
15:9 1280 x 768 16,32 bits
16:9 1280 x 720 16,32 bits
