recommended standard solutions

model/range

solution number

ep

x .1

none available

x 1

none available

x 10

442-30

x 100

442-300

x 1000

442-3000

with RE-10

442-30,000

ep-10

x 1

none available

x 10

KCl-70

x 100

KCl-700

x 1000

KCl-7000

with RE-10

KCl-70,000

standard solution equivalent values

solution

micromhos

number

microsiemens

ppm/nacl

ppm/442™*

442-30

46.7

21.8

30

442-300

445

214

300

442-3000

3900

2027

3000

442-30,000

30,100

18,235

30,000

KCl-70

70

32.8

45

KCl-700

700

340

478

KCl-7000

7000

3740

5687

KCl-70,000

70,000

47,999

84,983

* Myron L Company proprietary natural Water Standard

range extender

The RE-10 Range Extender is a useful accessory for

testing high conductivity solutions beyond the normal

range of your EP meter. inserting the RE-10 into a sample-

filled cell cup increases the maximum range ten times.

use the Range Extender whenever the reading is off the

scale.
using the re-10

1. Fill the cell cup three times to rinse it, but each time

insert the Range Extender to rinse it also.

2. Fill the cell cup with your sample. Push the Range

Extender into the cell cup, seating the o-ring seal.

3. use and read the meter in the normal manner. Multiply

the reading by 10.

4. For best accuracy, repeat the complete test with a fresh

sample.

5. When you’re done testing, remove the Range Extender.

Thoroughly rinse the cell cup and Extender with clean

water (preferably distilled or deionized) to eliminate

dried salts build-up. This is extremely important when

the instrument will be used to test high purity water.

calibrating the re-10

1. Calibrate your meter (without RE-10) using Standard

Solution number 442-3000 (EP) or KCL-7000 (EP10).

2. Fill the cell cup with 442-30,000 high conductivity

Standard Solution.

3. insert RE-10 and press the button. Multiply the reading

by 10 and compare it with the value on the Standard

Solution label. it they are not the same the RE-10 must

be recalibrated.

note: do not adjust the Calibration Control in your

meter.

4. adjust the white insert of the Extender as follows:

if the reading is too high — push or tap inward.

if the reading is too low — twist or pull outward with

pliers.

note: Each Range Extender is calibrated to a particular

meter. it should be recalibrated if it is to be used with

another Myron L meter.

porta pak

Carrying Case for use with all

Myron L portable meters, is foam-

lined and molded of sturdy aBS

plastic.

ordering

To order accessories or instruments contact your

nearest stocking distributor, or the Myron L Company.

if you also test ph

our reliable Model EP11/pH pDS meter may be ideal for

your application.

• Same four conductivity

ranges as EP10 plus

2-12 pH

• pH sensor built-in for

maximum protection,

but is field replaceable

• Automatic temperature

compensation

RE-10 RANGE EXTENDER

accessories continued

2450 impala Drive

Carlsbad, Ca 92010-7226

TELEPHonE: +1-760-438-2021

Fax: +1-760-931-9189

www.myronl.com

© Myron L Company 2008

EPoM WEB 05-08

Specifications subject to change without notice

Printed in the u.S.a.
