Operating Instructions
!
!
! Please make sure sensitivity level is set at
proper level.
Insert the lavalier, headset microphone or
instrument cable into the audio input connector
before power ON the transmitter.
Tighten the connector screw clockwise direction
as shown in (Figure 2) for a secured fit.
(Figure 2)
The ridge on the
connector must align and
match the indentation on
the socket when inserting
for a proper fit.
Capsule Connector
Headset
Lavalier
ON MODE SET
LCD Display Screen
 LCD Screen
 Parameters Screen
 AF (audio) MUTE
 Transmitter Battery Meter
14
15
16
17
14
17
15
16
Fully Lit LCD Display
0 1 0 2
GRP CH
