100K-2GSR Middle Wrench Assembly
Drawings 83
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
20008 Base Plate, Moving Assembly, Welded
2
2
20016A Linkage, Split Assembly
3
1
20028-245 Pin, Linkage Mount Assembly
4
2
20028-245B Pin, Linkage Mount Assembly
5
12
146 Thrust Bearing Assembly
6
1
20024 Linkage Assembly
7
4
20029-138AM W asher Assembly
8
1
20024-1 Stepped Linkage Arm Assembly
9
1
20002A Hook Assembly
10
1
20072 Nut Bearing Plate
11
1
20188 Adjust Nut Assembly
12
1
20274 Grease Bolt, Linkage Pin
13
19
806369 1.2-20 x 1.00 lg. Hex Bolt Grd. 9
14
21
810703_1.2 Lock W asher
15
16
PRP568-229 O Ring
16
4
PRP568-028 O Ring
17
4
20029-1 Washer
18
5
20229 Linkage Nut, Modified
19
7
807493-250 Cotter Pin
20
8
1103K1 Grease Fitting, Straight
21
4
PRP568-122 O Ring
22
2
1103K3 Grease Fitting, 90 Degree
23
2
1103K2 Grease Fitting, 45 Degree
24
1
20048A Stud, Cam Retro-fit
25
1
20047A Stop Cam Roller
26
2
20038 Pivot Bushing
27
2
20214-2A Bolt, Modified
28
6
806523_3.4-16 Flex Nut (31FK1216)
29
1
20028-362 Pin, Linkage Mount Assembly
30
2
20218 Bolt, W rench
31
1
20289-1A Lock Plate, W rench Bolt
32
1
20289-2A Lock Plate, W rench Bolt
33
3
806627_1-14 x 5.00 lg. Hex Bolt Grd. 9
34
1
806551_7.8-9 Flex Nut (31FKF1409)
35
1
20270 Hook Pin
36
1
98401A446_3.32 x 1.50 lg Cotter Pin
37
1
20204A Torque Cylinder Pin
38
1
98335A114 Hair Pin Retainer
39
1
20078 Stationary Jaw Cradle Assembly
40
1
20209-MID_Heel Die Holder Assembly, Middle
See Explosion
41
1
92384A092 Push Button Pin
42
2
806644_1 1.4-7 x 4.00 lg. Hex Bolt Grd. 9
43
1
20217 Shoulder Bolt
44
1
20269 Lock Plate
45
1
806594-500_1-14 Lock Nut
46
1
20211-MID_Hook Die Holder Assembly, Middle
See Explosion
47
1
808413_1.2-13 x .75 lg. Soc. Hd. Cap Screw
48
2
20198 Pivot Pin
49
2
20234 Pivot Sleeve
50
1
20200 Nut Stop
51
1
20202 Nut Stop Retainer
52
4
806004_3.8-16 x .75 Lg. Hex Bolt
53
4
810645_3.8 Lock W asher
54
1
20004A-2A Jaw Plate Assembly, W elded
55
1
20004A-2B Jaw Plate Assembly, W elded
56
1
807520_3.16 x 1.50lg. SS Roll Pin
57
1
H18S Grip Tilt Cylinder Assembly
See Explosion
58
1
20010-5 Reset Bumper W elded Assy
59
1
20010-4 Bumper
60
2
810705_1.2 Flat W asher
61
2
806221_1.2-13 Flex Nut (21FKF813)
62
4
806544_3.4-16 x 5.50 lg. Hex Bolt Grd. 9
63
1
20047A-1 Spacer, Roller
64
1
20023A Spring Mount Plate
65
2
806590_1-14 Nylock Nut
66
2
91074A038 W asher 1.0
67
1
SL5 Danger Label
68
4
807801_ Pop Rivet
69
2
20234-1 Pivot Sleeve Keeper
70
8
91074A036 Lock W asher Assembly, 3.4
71
8
806539_3.4-16 x 3.00 lg.Hex Bolt Grd. 9
72
1
806628-H Bolt, Grip Cylinder Middle W rench
