A11-LCH Multiplex Connector
Drawings 143
ITEM N O . Q TY./TH IS ASSY.
PART NO ./ D ESCR IPTIO N
C O MMENTS
1
1
70033 Male Coupler
2
1
807512_3.16 x .50lg. Roll Pin
3
12
90130A029 Rubber W asher Seal
4
1
70031 Panel Nut
5
1
70051 Female Coupler
6
1
70044 Swivel Nut
7
1
US-206-S Retainer Ring
8
20
A27 5.32 x 1.8 PTC Str. Fitting
9
2
A28 5.32 x 1.8 PTC Male Run T
10
2
A49 3.16 x 1.8 PTC Str. Fitting
