Decolav 1451 - Manual (Page 2)

112408
2
MODEL NUMBER: 1451
RECOMMENDED TOOLS
ROUGHING-IN DIMENSIONS
Customer Service: 561-274-2110
www.decolav.com LET YOUR DREAMS COME ALIVE, YOUR PASSIONS BECOME
REALITY, BE THE ENVY OF YOUR NEIGHBORS ®
Tape Measure
Pipe Wrench
Level
Plumber’s Putty
or Caulking
Drill
Scroll S aw Putty Knife
Pencil
1 3/8" [3.4925 cm]
16" [40.64 cm]
16" [40.64 cm]
8" [20.32 cm]
1 1/4"
[3.175 cm]
6 3/4"
[17.145 cm]
5"
[12.7 cm]
7"
[17.78 cm]
7" [17.78 cm]
34" [86.36 cm] 34" [86.36 cm]
6" [15.24 cm]
4 1/2" [11.43 cm]
1 3/4"
[4.445 cm]
Finished Wall
Drain
Hole
Faucet Hole
Sugg.
Countertop
Side View
Waste
Supplies as
required
Suggest
ed
Front View
Finished Floor
Top View
Fitting Line
Finished Floor
Finished Wall
Suggest
ed
