INSTALLATION INSTRUCTIONS
• STEP #3
• Apply Plumber’s Putty or Caulking around the underside of rim near the edge as shown.
• Carefully lower
Lavatory in place, align, and press fi rmly.
• Wipe off excess sealant.
• Refer to Figure #1.
•
NOTE: ALLOW SEALANT TO SET BEFORE PROCEEDING!
• STEP #4
• NOTE: DRAIN SHOWN, DECOLAV ® 9295 GRID DRAIN, IS A RECOMMENDED ACCESSORY AND NOT INCLUDED!
• Install Drain according to manufacturer’s installation instructions.
•
NOTE: DO NOT OVERTIGHTEN DRAIN!
• Refer to Figure #2.
Apply Plumber’s Putty
or Caulking here
Figure #1
Figure #2
Drain Nut
Tailpiece
Black Washer
Hard Washer
Black Washer
Hard Washer
Drain
Drain Nut
Tailpiece
Drain
Lavatory
