Model NuMber: AurA ® SerieS (1423, 1499)
4
o Apply Plumber’s Putty or Caulking around the underside of rim near the edge as shown.
o Carefully lower in place. Align and press firmly.
o Wipe off excess sealant.
o Refer to Figure 1.
• STEP #4
o Note: drAiN SHoWN, deColAV ® 9290 uMbrellA drAiN, iS A reCoMMeNded ACCeSSorY ANd Not iNCluded.
o Install Drain according to manufacturer’s installation instructions.
o
Note: do Not oVertigHteN drAiN.
o Refer to Figure 2.
Apply Plumber’s Putty
or Caulking Here
Drain
Tailpiece
Figure 2
Figure 1
Drain Nut
Thick Washer
Lavatory
Countertop
Tailpiece
Drain
Drain Nut
Thick Washer
• STEP #5
o Install waste system, faucet and water supply according to manufacturer’s installation instructions.
o
Note: WASte SYSteM, FAuCet ANd WAter SuPPlY Not iNCluded.
o Check for leakage.
