Model NuMber: 1421 SerieS
Customer Service: 561-274-2110
www.decolav.com
Let your dreams come aLive, your passions
become reaLity, be the envy of your neighbors
®
4
Figure #2
Lavatory
Countertop
Tailpiece
Drain Nut
Thick Washer
Drain
Drain
Tailpiece
Drain Nut
Thick Washer
• STEP #3
o Apply Plumber’s Putty or Caulking around the underside of rim near the edge as shown.
o Carefully lower
lavatory in place, align, and press firmly.
o Wipe off excess sealant.
o Refer to Figure #1.
o
Note: AlloW SeAlANt to Set beFore ProCeediNg!
• STEP #4
o Note: drAiN ShoWN, deColAV ® 9290 uMbrellA drAiN, iS A reCoMMeNded ACCeSSory ANd Not iNCluded!
o Install Drain according to manufacturer’s installation instructions.
o
Note: do Not oVertighteN drAiN!
o Refer to Figure #2.
Apply Plumber's Putty
or Caulking here
Figure #1
iNStAllAtioN iNStruCtioNS
