• STEP #3
o Apply Plumber’s Putty or Caulking around the underside of rim near the edge as shown.
o Carefully lower
Lavatory in place, align, and press firmly.
o Wipe off excess sealant.
o Refer to Figure #1.
o
NOTE: ALLOW SEALANT TO SET BEFORE PROCEEDING!
Apply Plumber’s Putty
or Caulking here
Figure #1
• STEP #4
o NOTE: DRAIN SHOWN, DECOLAV ® 9295 GRID DRAIN, IS A RECOMMENDED ACCESSORY AND NOT INCLUDED!
o Install Drain according to manufacturer’s installation instructions.
o
NOTE: DO NOT OVERTIGHTEN DRAIN!
o Refer to Figure #2.
Drain
Black Washer
Hard Washer
Drain Nut
Tailpiece
Black
Washer
Lavatory
Hard Washer Drain Nut
Drain
Tailpiece
Figure #2
Countertop
