Fault Tracing

The iX Panel K60 is working, but one or more keys are

not working

1. Check that the ﬂex cables are correctly ﬁtted.
2. Replace the front according to the

section.

Lines in display has wrong color or the display picture

is shifted

1. Check if the display has a wide vertical or horizontal area across the

display. It should be at least 2-3 cm wide with a grey or black color. See

for instructions on how to correct this.

2. Make sure the display cable is correctly ﬁtted.
3. Make sure the display cable is not folded or damaged in any way. Replace the

display cable according to the

section.

The iX Panel K60 will not restart after changing a

component

1. Remove and insert the battery again.

Low battery / No battery

1. Check that the battery is correctly ﬁtted in its holder.
2. If low battery/no battery voltage, replace the battery according to the

section.
