TxA Maintenance
4. Remove the Torx M3 screws (3) from the CPU card (5), and then remove the
CPU card (5).
Note:
It is not necessary to remove the connector plate.
5
4
4. Torx M3 Screw
5. CPU card
5. Assemble the CPU card (5) to the new back cover (1).
6. Connect the flex cable from the front unit to the CPU card (5).
7. Screw the Front and the back cover (1) together.
8. Power up the unit and run a selftest.
Beijer Electronics, MAEN021 13
