9

IEC POWER

JUMPER CABLE

IEC POWER

JUMPER CABLE

IEC POWER

JUMPER CABLE

IEC POWER

CABLE

A.C.

MAINS

NX10C

#1

NX10C

#2

NX10C

#3

NX10C

#4

LINE IN

LINK

LINE IN

LINK

LINE IN

LINK

LINE IN

When using LINK the level of each NX10C controls
the corresponding cabinet it is LINKed to.

As an example, NX10C #1 Level will affect the volume
of #2 and #3... If NX10C #2 is adjusted, #3... will be
affected (but not #1)

MULTIPLE NX10Cs ON SINGLE POLE

(LINKED operation)

connection-NX10C-SUB-POLE-LINKED-00-1v2
