Connection (parrallel), Multiple nx10cs on single pole – Yorkville NX10C User Manual
Page 10
8
IEC POWER
JUMPER CABLE
IEC POWER
JUMPER CABLE
IEC POWER
JUMPER CABLE
IEC POWER
CABLE
A.C.
MAINS
NX10C
#1
NX10C
#2
NX10C
#3
NX10C
#4
MULTIPLE NX10Cs ON SINGLE POLE
(parallel operation)
LINE IN
MIC IN
LINE IN
MIC IN
LINE IN
MIC IN
All inputs are in parallel so that each cabinet’s
controls will operate independently from each other
LINE IN
connection-NX10C-SUB-POLE-P
ARALLEL-00-1v2
