Page 2 04/14 Rev. B 151749
User Interface Detail
On/Off and Return to Status: Pressing this button quickly(holding for less than 1
second) will display the product temperature. Holding this key down for 5
seconds will disable/enable cooling and heating and the product temperature
will flash when cooling and heating is disabled.
Program: Pressing this button will display the programming selections.
Up/Down Arrow: These keys navigate the user through the menu structure and
increase/decrease values of set points.
Select: This key is used to navigate through the menu structure.
Cooling Indicator: This key is only used for indicating cooling status via the LED.
Alarm: The LED indicates the unit is in an alarm condition. Pressing this key
while the buzzer is sounding will silence the alarm buzzer.
Down Arrow
Up Arrow Program
On/Off and
Return to Status
Not Used
Select
Cooling
Indicator
4-Digit Display
Alarm
