APPENDIX A / ANNEXE A
BROAD SCAN (HD/SDI)
PAGE 42
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION
ne ne
Communication
port
selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
nr
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
ns
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na na
IP address and port selection (for
modification)
Rd/Wr
0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw nw
First byte of the address selected by the
na command.
Rd/Wr
0 255
nx nx
Second byte of the address selected by
the na command.
Rd/Wr
0 255
ny ny
Third byte of the address selected by
the na command.
Rd/Wr
0 255
nz nz
Forth byte of the address selected by the
na command.
Rd/Wr
0 255
np np
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk nk
netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2
255.255.255.252
3
255.255.255.248
.............
8
255.255.255.0.............
24
255.0.0.0
nt TCP
protocol
selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
CONTROLS COMMANDS / COMMANDES DE CONTRÔLE
xU
xU
Device
version
Rd
0 65535 The value is displayed in decimal and should be
converting in hexadecimal to obtain the version.
Example: xU262262 (dec) = 106 (hex)
106 = Version 1.06
ZT
ZT
Zoom type
Rd/Wr
0
1
0 = Direct zoom
1 = Dynamic zoom
YL
YL
Auto frame
Rd/Wr
0
1
0 = OFF
1 = ON
YK
YK
Front panel locking selection.
Rd/Wr
0
3
0 = unlocks all buttons.
1 = locks Menu buttons.
3 = locks all buttons
ws
ws
Standby function (ON/OFF)
Rd/Wr
0
1
0 = ON
1 = OFF
wt
wt
Stand by time
Rd/Wr
0
8
0 = 0 second
1 = 1 min
2 = 5 min
3 = 10 min
4 = 15 min
5 = 30 min
6 = 60 min
7 = 90 min
8 = 120 min
wm
wm
Standby
mode
activation
Rd/Wr
0
2
0 = Sync.loss
1 = Standby time
2 = Sync. loss + time
YE
YE
Erase memories
Rd/Wr
0
1
1 = set all the parameters to the default value
(automatic reset).
YR
YR Default
value.
Rd/Wr
0 1
1
=
erase all memories (automatic reset).
NOTE: Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
