Step 3
ASSEMBLY
13
15
14
Hardware Used
M4X6 Bolts X 3
Hardware Used
4mm washer X 5
M4 X 8 bolt X 5
Step 3
Step 4
4
3
4
5
14
Step 4
Connect the upper pole (4) on the low
pole (5) , fix it with 3pcs M4×6 bolt (14) .
Insert the burner assembly (3) in the
upper pole (4) , fix it with 5pcs 4mm
washer (15) and 5pcs M4×8 bolt (13) .
13
15
