Doyon PIZ3 - Manual (Page 20)

C3
#29 (3.5mm)
1 1/4 [31.80]
5/32 [3.98]
2 1/2 [63.50]
2 9/16 [65.09]
2 3/8 [60.33]
5/32 [3.97]
1
2
PIECE #1
THICKNESS 3/32 (2.4mm)
PIECE #2
THICKNESS 1/8 (3.2mm)
INSULATION
COMBUSTION−CHAMBER
SPACER
NOZZLE #23
(3.9mm)
COMBUSTION−CHAMBER
NOZZLE
GROUND PLATE
PROTECTOR FOR MINERAL WOOL
4 HOLES
Ш7/16
[Ш
11.10]
ON
%
%
1 5/8 [
Ø
41.28]
4 HOLES
Ш5/16
[Ш
7.94]
ON
%
%
1 5/8 [
Ø
41.28]
PIZ6G−N
ADJUSTMENT BURNER
PIZ6G NATURAL GAS
SUPPLY PRESSURE: 7" W.C. (20/25 Mbar) MANIFOLD PRESSURE: 3.3" W.C. (8.25 Mbar) IGNITION WIRE: 45" DETECTION WIRE: 36" HIGH LIMIT: 700° F LOCKED: 645° F THERMOSTAT: 550° F BTU: 70 000
C-3
