Doyon PIZ3 - Manual (Page 18)

C1
#29 (3.5mm)
1 1/4 [31.80]
5/32 [3.98]
2 9/16 [65.09]
2 3/8 [60.33]
5/32 [3.97]
1
2
PIECE #1
THICKNESS 3/32 (2.4mm)
PIECE #2
THICKNESS 1/8 (3.2mm)
INSULATION
COMBUSTION−CHAMBER
SPACER
NOZZLE #23
(3.9mm)
COMBUSTION−CHAMBER
NOZZLE
GROUND PLATE
PROTECTOR FOR MINERAL WOOL
8 HOLES
Ш7/16
[Ш
11.10]
ON
%
%
1 5/8 [
Ø
41.28]
PIZ3G−N
ADJUSTMENT BURNER
PIZ3G NATURAL GAS
SUPPLY PRESSURE: 7" W.C. (20/25 Mbar) MANIFOLD PRESSURE: 3.5" W.C. (8.75 Mbar) IGNITION WIRE: 30" DETECTION WIRE: 30" HIGH LIMIT: 700° F LOCKED: 645° F THERMOSTAT: 600° F BTU: 70 000
C-1
