8 MSC-3Dx
FUNCTIONS
Either Current Speed, Clock Time or Cadence can be selected on the upper display.
Current Speed
The speed icon flashes. The data is updated once a second.
Range: 0.0 (3.0) ~ 65.9 mph [0.0 (4.0) ~ 105.9 km/h]
Cadence (the number of pedal revolutions)
The cadence icon flashes. The data is updated once a second.
Range: 0 (20) ~ 299rpm
Clock Time
The clock icon flashes. Time is displayed in 24 hour or 12 hour.
NOTE:
When the speed scale is "km/h", the clock time is always displayed in a 24-hour clock. When the
"mph", the clock time is always displayed in a 12-hour clock.
Heart Rate
When the chest belt heart rate sensor is attached to the body, the heart rate icon flashes and
the Heart Rate is displayed in real time.
Display Range: 0~299 bpm
Select the desired function with MODE button on the lower display. Refer to page 6, "Mode
Button" for navigation to each function.
Tm Elapsed Time (Timer)
The time lapse from the start to the present time is shown in hours, minutes and seconds. The
elapsed time data returns to zero with the reset option.
Range: 0.00.00~9.59.59
MxP Maximum Heart Rate
The maximum heart rate from the start to the present time is displayed. This is the sub function
of Elapsed Time. The Max Heart Rate data returns to zero when the MSC is reset.
Range: 0 ~ 299 bpm
Clock Time
Current time is displayed in 24 hour or 12 hour time. The Clock can be moved to the upper
display. (Current Speed would then appear in the lower display.) (See page 7)
Upper Display
Middle Display
Lower Display
