Procedures
8 ATP-CNX-020 Rel. 1.2, Doc. Rev. 01.06
Aastra CNX Quick Installation and Setup Guide
Configuring the network settings
Requirements
The following is required before you configure the Aastra CNX for the first time:
• The Aastra CNX must physically be connected to your console using an
RS-232/DB-9 cable.
• The Aastra CNX must physically be connected to your network interface via the Ethernet
port(s).
• The Aastra CNX must be turned on.
• You must be running a terminal emulator on your PC. Terminal emulator must be set as
follows:
— Baud Rate
9600
— Data 8 bit
— Parity None
— Stop 1 bit
— Flow Control None
The Aastra CNX setup script allows you to configure the following:
(1) Run network and time configuration
The following procedure describes how to configure the network settings.
Note: If at any time during the initial configuration process, you want to
backout of the configuration, press to cancel.
Configure the network settings 7
