Spec
Sheet
USer iNTerfaCeS (remoTe SiDe)
Craft Port:
RS-232 (DCE)
front Panel: status LEDs
ProviSioNaBLe oPTioNS Equalization, SmartJack and special loopbacks, power feed
mode, T1 frame format, BER alarm threshold, loopback timeout,
alarm disable, DSX-1 line code, AIS on 1LP, AIS on SmartJack
NREM, DS0 blocking, RLOS alarm enable, alarm pattern, BPV
Transparency
LiNe PoWeriNG
modes:
Low, auto, high, disable
Line voltage: ≤140 VDC or ±112 VDC
PoWer
Co Supply:
-48 VDC (nom.) (-42.5 VDC to -56.5 VDC)
eNviroNmeNTaL (oPeraTiNG)
Humidity:
5% to 95% (non-condensing)
Temperature: -40°F to +149°F (-40°C to +65°C)
NeBS Compliance NEBS Level 3 Class A2 or A3 per GR-1089-CORE depending on
the operation mode Applicable Sections: GR-63-CORE, GR-499-
CORE, GR-1089-CORE, SR-3580
regulatory Compliance UL 1459, CSA, FCC Rules Part 15 Class A
Specifications (Cont'd)
