Rapid Indoor Fiber Distribution Hub 3000i
Ordering Information
Distribution Fiber Count
072 72 fiber distribution
144 144 fiber distribution
216 216 fiber distribution
288 288 fiber distribution
360 360 fiber distribution
432 432 fiber distribution
Catalog Number
FD3-M __ __ __ __ __ __ __ __ __ __ __
Cabinet Size
K Indoor 72 cabinet
M Indoor 288 cabinet
N Indoor 432 cabinet
Adapter Style
J SC/APC
N SC/UPC
No. Splitter Modules
0 No splitters
1 1 splitter
2 2 splitters
4 4 splitters
Splitter Type
0 No splitters
A 1x32 standard
C 1x16 standard
G 2x32 standard-power
J 1x8 standard
L Dual 1x8 standard
M Dual 1x16 standard
N 1x4 standard
P 2x16 standard
U Dual 1x4 standard
Distribution Cable Type
R Riser ribbon stub
L Riser loose tube stub
V Loose tube pigtails
0 Ribbon pigtails
M MT connectors
Distribution Stub Length
A 50' stub
0 No stub
Distribution Cable Configuration
A All 72 fiber stubs
B All 144 fiber stubs
C Highest stub count possible
D All 144 fiber stubs, except first 1-72
0 Spliced distribution
M MT patch
Feeder Fiber Count
A 12 fibers
B 24 fibers
C 48 fibers
D 72 fibers
Feeder Cable Length
A 100' stub top entry
0 Spliced input
Feeder Cable Type
A Indoor/outdoor ribbon stub
B Riser ribbon stub
C Indoor/outdoor loose tube stub
D Riser loose tube stub
E Stranded pigtails (splice)
F Ribbon pigtails (splice)
