- 48 -
Four Screws
Quatre vis
Cuatro Tornillos
➢ Lay unit on floor bottom up with
nozzle flat.
➢ Install the four screws to the nozzle
cover.
➢ Route nozzle hose to hose holder.
Align nozzle hose bracket with
retaining bracket on body and slide
down unit it clicks into place.
➢ Return the vacuum cleaner to the
upright position before plugging
into an electrical outlet.
2
1
➢ Place the vacuum in the upright
position standing on the handle.
This will minimize wheel
interference when installing nozzle
bottom plate.
➢ Reinstall nozzle cover by (1)
aligning front edge of the cover with
the nozzle and (2) rotating to
installed position.
