- 40 -
Replacing HEPA Media Exhaust Filter
Latch
Loquet
Lengüeta
Tab
Languette
Lengüeta
Slot
Fente
Ranura
Air Flow
Exhaust Filter
Filtre d’évacuation
Filtre de salida
Air Flow
➢ The HEPA media exhaust filter
removes dirt from exhaust air.
➢ Check filter after emptying dust bag.
Replace when dirty.
➢ Filter cannot be cleaned and should
be replaced at least once each year.
Part Number: MC-V194H
➢ Turn off and unplug the vacuum
cleaner.
➢ Press latch to remove exhaust filter
cover.
➢ Grasp the exhaust filter and pull out
to remove.
➢ Place the new filter into the vacuum
cleaner with the foam seal down.
➢ Be sure air flow arrow on filter is
pointing upward.
➢ Reinstall the exhaust filter cover by
inserting the tab into the slot in the
vacuum cleaner. Press firmly to
snap exhaust filter cover into place.
